Engineering Plastics
PA66 GF30 | Glass Fiber Reinforced Nylon 66 30% Glass Filled Manufacturer & Supplier
PA66 GF30 glass fiber reinforced nylon 66 with 30% glass fill. High tensile strength, stiffness & heat resistance. Manufacturer direct supply. TDS & samples available.
Specifications
- Density
- 1.37 g/cm³
- Tensile Strength
- 180-200 MPa
- Flexural Strength
- 260-280 MPa
- Flexural Modulus
- 10,000-12,000 MPa
- Impact Strength (Notched Izod)
- 12-15 kJ/m²
- Heat Deflection Temperature (1.8MPa)
- 245-255°C
- Melting Point
- 255-265°C
- Water Absorption (24h)
- 1.0-1.5%
- Mold Shrinkage
- 0.3-0.7%
High Strength PA66 GF30 Glass Fiber Reinforced Nylon 66 Raw Material
PA66 GF30 is a high-performance engineering thermoplastic reinforced with 30% glass fiber, based on polyamide 66 (nylon 66) resin. This glass filled nylon delivers exceptional mechanical strength, dimensional stability, and heat resistance compared to unfilled PA66, making it widely used in automotive parts, industrial components, and electrical enclosures.
As a professional PA66 GF30 manufacturer and supplier in China, we provide virgin nylon 66 GF30 compound with consistent quality, competitive pricing, and reliable delivery for global buyers.
🔧 Key Properties & Benefits
High tensile strength — approximately 180-200 MPa, nearly 2× stronger than unfilled nylon 66
Enhanced stiffness & rigidity — 30% glass fiber reinforcement significantly improves flexural modulus
Superior impact resistance — suitable for structural and load-bearing applications
Excellent dimensional stability — minimal warpage and low moisture absorption
Heat resistant — continuous use temperature up to 150°C, short-term peak up to 220°C
Good fatigue resistance — ideal for repetitive stress environments
Chemical resistance — resistant to oils, greases, solvents, and automotive fluids
Good electrical insulation properties
🏭 Applications
Industry | Typical Parts |
Automotive | Engine covers, intake manifolds, radiator tanks, gear housings, bearing cages, brake components |
Electrical & Electronics | Circuit breaker housings, connector bodies, switchgear components, coil bobbins |
Industrial Machinery | Gears, bushings, bearings, rollers, pump impellers, valve seats |
Consumer & Appliance | Power tool housings, appliance brackets, fan blades, zipper pulls |
Aerospace & Military | Structural brackets, drone components, lightweight rigid parts |
⚙️ Processing Guidelines
- Pre-drying: 80°C for 4-6 hours (moisture content < 0.2% before processing)
- Injection molding temperature: 270-290°C
- Mold temperature: 80-120°C (higher mold temp improves surface finish and crystallinity)
- Compatible with standard injection molding and extrusion equipment
📦 Packaging & Ordering
Item | Details |
Packaging | 25 kg/bag (standard), or custom packaging available |
MOQ | 1 × 20'FCL (approx. 26-27 tons), small trial orders negotiable |
Payment Terms | T/T (30% deposit, 70% before shipment) |
Trade Terms | EXW / FOB / CIF |
Lead Time | within 5 working days after payment confirmed |
Technical Documents | TDS, COA, MSDS provided upon request |
Samples | Small trial order |
✅ Why Choose Us
Direct manufacturer supply — competitive pricing with full quality control
Stable raw material sourcing — sourced from major Chinese petrochemical producers
Technical support — grade selection, material substitution advice, and application guidance
Export-ready — professional export packaging, full documentation for customs clearance
Flexible MOQ — support trial orders for new customers
📞 Contact Us
Looking for a reliable PA66 GF30 supplier in China? Contact us today for price quotation or technical consultation.
